Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | 1070814 |
| Body Style | T-slot |
| Connection Type | Cable with connector M8, 3-pin, 0.3 m |
| Dropout Voltage | ≤ 2 V |
| Housing Material | Plastic |
| Hysteresis | < 0.8 mT |
| IP Rating | IP65 ; IP67 |
| Length | 1.122" (28.50mm) |
| Material, Cable | PUR |
| Output | PNP |
| Output Type | NO |
| Power Dissipation | ≤ 8 mA (without load) |
| Series | |
| Supply Voltage | 10 V DC ... 30 V DC (Limit values when operated in short-circuit protected network: max. 8 A) |
| Type | Magnetic Cylinder |
