| Product Attribute | Attribute Value |
|---|---|
| Application | Automatic Barrier ; Public Lighting ; Stretch Wrapping Machine |
| Depth | 2.657" (67.5mm) |
| Dimensions | 107.6 x 72 x 67.5 mm |
| Family Name | Millenium 3 Family |
| For Use With | Micro Controllers ; M3 Controllers ; M3Smart Expandable Controllers |
| Input Type | Digital |
| Length | 4.236" (107.6mm) |
| Mounting Type | DIN Rail Mount |
| Number of Inputs | 6 Input |
| Number of Outputs | 4 Output |
| Output Type | Relay |
| Primary Type | Expansion |
| Series | |
| Special Features | Sandwich Extension |
| Standards | UL Listed, CSA Certified, EC, ISO 9001, ISO 14001, OHSAS 18001 |
| Supply Voltage | 24 VDC |
| Type | I/O |
| Width | 2.835" (72mm) |
Overview
Crouzet Millenium 3 Family | XE10 / XR10 Series — Easiest Logic Controller With Display:
The Millenium 3 Smart logic controller is the easiest programmable module to use on the market. Easy to program thanks to M3 Soft, it enables the control and monitoring of machines and automation installations with up to 50 I/Os. Easy to program and to implement, it enables the control and monitoring of machines and automation installations with up to 50 I/O. It is positioned right at the heart of the Automation range. Millenium 3 offers both standard and customized product solutions for a range of applications, including automatic barriers, automatic doors, turnstiles, sectional doors and disabled access ramps.
Easy to program and to implement, it enables the control and monitoring of machines and automation installations with up to 50 I/O. It is positioned right at the heart of the Automation range. Millenium 3 offers both standard and customized product solutions for a range of applications, including automatic barriers, automatic doors, turnstiles, sectional doors and disabled access ramps.
Digital Sandwich Expansion Features:
Standard Digital Expansion Features:
Millenium 3 Family Features:
